FluidLogic VMR POD Assembly
FluidLogic VMR POD Assembly
Couldn't load pickup availability
The FluidLogic VMR System is the most advanced hydration solution for drivers, delivering effortless, hands-free hydration at the push of a button. Designed for peak performance, this fully programmable system keeps you hydrated without distraction—so you can focus on winning.
Customizable Hydration Control via iOS App:
✔ Adjust volume of dispensed water
✔ Adjust pressure of dispensed water
✔ Adjust hydration reminder interval
✔ Adjust LED idle and reminder brightness
What’s New for 2025?
✔ Upgraded Pump – Automatic priming, even when dry
✔ Low Power Draw – Just 0.6 amps for maximum efficiency
✔ Extreme Reliability – Built for the most demanding conditions
✔ Steering Wheel Integration – Use your existing steering wheel drink button. Our drink signal supports both switch-to-ground and switch-to-positive configurations on the same wire
THIS IS FOR USERS WHO ALREADY HAVE EITHER MAGLOCK DUO OR MAGLOCK HYDRO DELIVERY SYSTEM.
PART NUMBER: VMR-PODAS
What’s Included
What’s Included
Hydration System Components:
✔(1) Pod with mount and hose clamps
✔(1) 12V cable
✔(1) Pod-to-dash cable
✔(1) Steering wheel microbutton
✔(1) Fluidline with heat shrink (Bottle to Pod and Pod to Hub for Duo setups)
Specs & Material
Specs & Material
- Pod Dimension: 180.6 mm x 70 mm x 68.4 mm
- Pod Weight: 320g
- Supply Voltage: +6VDC to +18VDC
- Supply Current:
- Idle: 0.04A
- Pumping: <1A at 12VDC (depending on fluid path components) - System Flow Rate: 750ml/min
- BLE 5.2 connectivity to Fluidlogic accessories
- Environmental: IP67
- System Storage Temp: 3 – 85C
- Usage Temp: 3 – 50 C
- Water Temperature: 3 – 50C
- Altitude: Less than 2000m
- iOS 13 and up App
- Certifications for both USA/EU
- USA – Prop 65
Customizable Hydration Control via iOS App:
✔ Adjust the volume of dispensed water
✔ Adjust the pressure of dispensed water
✔ Adjust the hydration reminder interval
✔ Adjust the LED idle and reminder brightness
